1.The rack construction with the wallboard structure after high-strength holistic processing has great working stability and is durable in use;
2.The 650-line color high-definition camera can reach 70-times amplification ratio, present clear images, possess high resolution ratio, and substantially improve the precision of the plate;
3.The lifting of plate roller structure adopts the gear motor drive control, which largely facilitates the operations of the plate;
4.The complete machine adopts the centralized control of circuits, which is convenient for operations and has relatively high degree of automation;
5.The 19-inch high-resolution liquid crystal display provides clear and bright images and effectively alleviates the visual fatigue of operating workers.
| MAIN TECHNICAL PARAMETERS： | |
| Model | |
| Effective Width of the Plate | 360mm |
| Diameter of the Central Spindle | Φ320mm |
| Precision of the Plate | Better than ±0.15mm |
| Resolution Ratio of the Camera Lens | 650 Line |
| Maximum Focal Length of the Camera Lens | 70 Times |
| Focusing Mode of the Camera Lens | Manual Variation of Focal Length and Manual Focusing |
| Gear Motor Drive | Approximate to 300mm/min (Plate Roller) |
| Overall Diameter（L×W×H） | 1500×700×1700mm |
