Main technical parameter:
| Max. Unwinding Diameter | 1100mm |
| Max. Folding Length | 350mm |
| Min. Folding Length | 100mm |
| Web Width | 80-560mm |
| Min.Slitting Width | 60mm |
| Max Stacked Height | 300mm |
| Motor | 5.5KW |
| Power Supply | 220V60hz Single Phase |
| Max. Machine Speed | 200Repeats/min |
| Dimensions of Folder | 1360mm×1400mm×1280mm |
| Weight of Folder | 1200kgs |
| Dimensions of Conveyor | 1900mm*880mm*770mm |
| Weight of Conveyor | 700kgs |
| Weight of Unwinder | 400kgs |
| Dimensions of Unwinder | 1100mm*1200mm*1000mm |
